使用 Open Policy Agent 实现可信镜像仓库检查

从互联网（或可信镜像仓库库以外的任何地方）拉取未知镜像会带来风险——例如恶意软件。但是还有其他很好的理由来维护单一的可信来源，例如在企业中实现可支持性。通过确保镜像仅来自受信任的镜像仓库，可以密切控制镜像库存，降低软件熵和蔓延的风险，并提高集群的整体安全性。除此以外，有时还会需要检查镜像的 tag，比如禁止使用 latest 镜像。

这今天我们尝试用“策略即代码”的实现 OPA 来实现功能。

还没开始之前可能有人会问：明明可以实现个 Admission Webhook 就行，为什么还要加上 OPA？

确实可以，但是这样策略和逻辑都会耦合在一起，当策略需要调整的时候需要修改代码重新发布。而 OPA 就是用来做解耦的，其更像是一个策略的执行引擎。

什么是 OPA

Open Policy Agent（以下简称 OPA，发音 “oh-pa”）一个开源的通用策略引擎，可以统一整个堆栈的策略执行。OPA 提供了一种高级声明性语言（Rego），可让你将策略指定为代码和简单的 API，以从你的软件中卸载策略决策。你可以使用 OPA 在微服务、Kubernetes、CI/CD 管道、API 网关等中实施策略。

Rego 是一种高级的声明性语言，是专门为 OPA 建立的。更多 OPA 的介绍可以看 Open Policy Agent 官网，不想看英文直接看这里。

2021-07-09-18-26-25

现在进入正题。

启动集群

启动 minikube

minikube start

创建用于部署 OPA 的命名空间

创建并切换到命名空间 opa （命名空间的切换使用 kubens，更多工具介绍见这里）

kubectl create namespace opa
kubens opa

在 Kubernetes 上部署 OPA

Kubernetes 和 OPA 间的通信必须使用 TLS 进行保护。配置 TLS，使用 openssl 创建证书颁发机构（certificate authority CA）和 OPA 的证书/秘钥对。

openssl genrsa -out ca.key 2048
openssl req -x509 -new -nodes -key ca.key -days 100000 -out ca.crt -subj "/CN=admission_ca"

为 OPA 创建 TLS 秘钥和证书：

cat >server.conf <<EOF
[req]
req_extensions = v3_req
distinguished_name = req_distinguished_name
prompt = no
[req_distinguished_name]
CN = opa.opa.svc
[ v3_req ]
basicConstraints = CA:FALSE
keyUsage = nonRepudiation, digitalSignature, keyEncipherment
extendedKeyUsage = clientAuth, serverAuth
subjectAltName = @alt_names
[alt_names]
DNS.1 = opa.opa.svc
EOF

注意 CN 和 alt_names 必须与后面创建 OPA service 的匹配。

openssl genrsa -out server.key 2048
openssl req -new -key server.key -out server.csr -config server.conf
openssl x509 -req -in server.csr -CA ca.crt -CAkey ca.key -CAcreateserial -out server.crt -days 100000 -extensions v3_req -extfile server.conf

为 OPA 创建保存 TLS 凭证的 Secret：

kubectl create secret tls opa-server --cert=server.crt --key=server.key

将 OPA 部署为准入控制器（admission controller）。

admission-controller.yaml：

# 授权 OPA/kube-mgmt 对资源的只读权限
# kube-mgmt 会同步资源信息给 OPA，以便在策略中使用
kind: ClusterRoleBinding
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: opa-viewer
roleRef:
  kind: ClusterRole
  name: view
  apiGroup: rbac.authorization.k8s.io
subjects:
- kind: Group
  name: system:serviceaccounts:opa
  apiGroup: rbac.authorization.k8s.io
---
# 为 OPA/kube-mgmt 定义角色来在 configmaps 中更新策略状态
kind: Role
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  namespace: opa
  name: configmap-modifier
rules:
- apiGroups: [""]
  resources: ["configmaps"]
  verbs: ["update", "patch"]
---
# 为 OPA/kube-mgmt 授予角色
kind: RoleBinding
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  namespace: opa
  name: opa-configmap-modifier
roleRef:
  kind: Role
  name: configmap-modifier
  apiGroup: rbac.authorization.k8s.io
subjects:
- kind: Group
  name: system:serviceaccounts:opa
  apiGroup: rbac.authorization.k8s.io
---
kind: Service
apiVersion: v1
metadata:
  name: opa
  namespace: opa
spec:
  selector:
    app: opa
  ports:
  - name: https
    protocol: TCP
    port: 443
    targetPort: 8443
---
apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    app: opa
  namespace: opa
  name: opa
spec:
  replicas: 1
  selector:
    matchLabels:
      app: opa
  template:
    metadata:
      labels:
        app: opa
      name: opa
    spec:
      containers:
        # WARNING: OPA is NOT running with an authorization policy configured. This
        # means that clients can read and write policies in OPA. If you are
        # deploying OPA in an insecure environment, be sure to configure
        # authentication and authorization on the daemon. See the Security page for
        # details: https://www.openpolicyagent.org/docs/security.html.
        - name: opa
          image: openpolicyagent/opa:0.30.1-rootless
          args:
            - "run"
            - "--server"
            - "--tls-cert-file=/certs/tls.crt"
            - "--tls-private-key-file=/certs/tls.key"
            - "--addr=0.0.0.0:8443"
            - "--addr=http://127.0.0.1:8181"
            - "--log-format=json-pretty"
            - "--set=decision_logs.console=true"
          volumeMounts:
            - readOnly: true
              mountPath: /certs
              name: opa-server
          readinessProbe:
            httpGet:
              path: /health?plugins&bundle
              scheme: HTTPS
              port: 8443
            initialDelaySeconds: 3
            periodSeconds: 5
          livenessProbe:
            httpGet:
              path: /health
              scheme: HTTPS
              port: 8443
            initialDelaySeconds: 3
            periodSeconds: 5
        - name: kube-mgmt
          image: openpolicyagent/kube-mgmt:0.11
          args:
            - "--replicate=v1/pods"
      volumes:
        - name: opa-server
          secret:
            secretName: opa-server
---
kind: ConfigMap
apiVersion: v1
metadata:
  name: opa-default-system-main
  namespace: opa
data:
  main: |
    package system

    import data.kubernetes.validating.images

    main = {
      "apiVersion": "admission.k8s.io/v1beta1",
      "kind": "AdmissionReview",
      "response": response,
    }

    default uid = ""

    uid = input.request.uid

    response = {
        "allowed": false,
        "uid": uid,
        "status": {
            "reason": reason,
        },
    } {
        reason = concat(", ", images.deny)
        reason != ""
    }
    else = {"allowed": true, "uid": uid}

kubectl apply -f admission-controller.yaml

接下来，生成将用于将 OPA 注册为准入控制器的 manifest。

cat > webhook-configuration.yaml <<EOF
kind: ValidatingWebhookConfiguration
apiVersion: admissionregistration.k8s.io/v1beta1
metadata:
  name: opa-validating-webhook
webhooks:
  - name: validating-webhook.openpolicyagent.org
    rules:
      - operations: ["CREATE", "UPDATE"]
        apiGroups: ["*"]
        apiVersions: ["*"]
        resources: ["pods"]
    clientConfig:
      caBundle: $(cat ca.crt | base64 | tr -d '\n')
      service:
        namespace: opa
        name: opa
EOF

生成的配置文件包含 CA 证书的 base64 编码，以便可以在 Kubernetes API 服务器和 OPA 之间建立 TLS 连接。

kubectl apply -f webhook-configuration.yaml

查看 OPA 日志：

kubectl logs -l app=opa -c opa -f

定义策略并通过 Kubernetes 将其加载到 OPA

这里我们定义了对容器镜像的检查：

  • 是否来自受信任的仓库
  • 是否使用了 latest tag 的镜像

image-policy.rego

package kubernetes.validating.images

deny[msg] {
    some i
    input.request.kind.kind == "Pod"
    image := input.request.object.spec.containers[i].image
    endswith(image, ":latest")
    msg := sprintf("Image '%v' used latest image", [image])
} {
    some i
    input.request.kind.kind == "Pod"
    image := input.request.object.spec.containers[i].image
    not startswith(image, "192.168.64.1:5000")
    msg := sprintf("Image '%v' comes from untrusted registry", [image])
}

kubectl create configmap image-policy --from-file=image-policy.rego

检查 configmap 的 annotation openpolicyagent.org/policy-status 值是否 为 '{"status":"ok"}'。否则，就要根据报错信息处理问题。

注：192.168.64.1:5000 是笔者本地容器运行的一个私有仓库。

version: '3.6'
services:
  registry:
    image: registry:2.7.1
    container_name: registry
    restart: always
    environment:
      REGISTRY_HTTP_ADDR: 0.0.0.0:5000
      REGISTRY_STORAGE: filesystem
      REGISTRY_STORAGE_DELETE_ENABLED: 'true'
      REGISTRY_STORAGE_FILESYSTEM_ROOTDIRECTORY: /var/lib/registry
    ports:
      - '5000:5000'
    volumes:
      - '/Users/addo/Downloads/tmp/registry:/var/lib/registry'

测试

pod-bad-repo.yaml

apiVersion: v1
kind: Pod
metadata:
  creationTimestamp: null
  labels:
    run: web-server
  name: web-server
spec:
  containers:
  - image: nginx:1.21.1
    name: web-server
    resources: {}
  dnsPolicy: ClusterFirst
  restartPolicy: Always
status: {}

kubectl apply -f pod-bad-repo.yaml
Error from server (Image 'nginx:1.21.1' comes from untrusted registry): error when creating "pod-bad-repo.yaml": admission webhook "validating-webhook.openpolicyagent.org" denied the request: Image 'nginx:1.21.1' comes from untrusted registry

pod-bad-tag.yaml

apiVersion: v1
kind: Pod
metadata:
  creationTimestamp: null
  labels:
    run: web-server
  name: web-server
spec:
  containers:
  - image: 192.168.64.1:5000/nginx:latest
    name: web-server
    resources: {}
  dnsPolicy: ClusterFirst
  restartPolicy: Always
status: {}

kubectl apply -f pod-bad-tag.yaml
Error from server (Image '192.168.64.1:5000/nginx:latest' used latest image): error when creating "pod-bad-tag.yaml": admission webhook "validating-webhook.openpolicyagent.org" denied the request: Image '192.168.64.1:5000/nginx:latest' used latest image

pod-ok.yaml

apiVersion: v1
kind: Pod
metadata:
  creationTimestamp: null
  labels:
    run: web-server
  name: web-server
spec:
  containers:
  - image: 192.168.64.1:5000/nginx:1.21.1
    name: web-server
    resources: {}
  dnsPolicy: ClusterFirst
  restartPolicy: Always
status: {}

kubectl apply -f pod-ok.yaml
pod/web-server created

总结

策略即代码，以代码的实现表达策略；在通过策略与执行引擎的解耦分离，让策略更加的灵活。

后面我们再探索 OPA 的更多场景。
